Slugging Tablet Press / Bolus Tablet Press for Veterinary
Features of Slugging Tablet Press / Bolus Tablet Press for Veterinary :
Slugging Tablet Press Bolus Tablet Press for Veterinary
* Square GMP Model
* Heavy duty press construction to manufacture Veterinary Bolus Tablet
* CI body and CI middle plate
* Paint free tablet manufacturing zone
* Turret of special grade iron casting
* Upper punch penetration
* Electronic digital tablet cum RPM counter
* Inter lock switches to all Guards
* Double sided lifting cams
* Lower guard of polished stainless steel & upper guards of acrylic material
* Aluminum turret guards
* Imported needle roller bearing provided at the bottom of turret
* Effective dust extraction nozzles
* Variable speed pulley
* One shot lubrication system
* Antsi vibration mounts
* Reverse direction motion protection is provided to avoid accident
* Available with AC variable drive & electromagnetic clutch (Optional)
Optional Parts/ Accessories available with the Slugging Tablet Press / Bolus Tablet Press for Veterinary:
* A. C. variable drive
* SS 316 contact parts
* Nickel plating on turret
* Poly carbonate upper cabinet guard
* Hopper granule level sensor
* Intermittent auto lubrication pump
Technical Specifications of Slugging Tablet Press / Bolus Tablet Press for Veterinary:
Model TPCV - 8 Stations TPCV - 12 Stations
Number of Station 8 12
Type Of Tooling Special Special
Output tablets / hour 10,560 at 22 RPM & 5,760 at 12 RPM 15,840 at 22 RPM & 8,640 at 12 RPM
Max. Operating Pressure (Tons) 12 12
Max. Tablet Diameter (mm) 40 40
Depth of Fill (mm) 30 30
Upper Punch Penetration (mm) 1.5 – 8 1.5 – 8
Main Electric Motor 5 HP, 930 RPM, 3 PH, 415 V, 50 Hz
Overall Dimension (mm) 980 x 1020 x 1820
Net Weight (kgs) 1000
Packing Dimension (mm) 1320 X 1320 X 2260
Gross Weight (kgs) 1500
Note: We reserve right to change specifications without any prior notice.
